![JetGuard_Family_B_With_Brand_20kw_10kw_20210218_5690-Web Two JetGuard underground mine dewatering pumps](https://www.pumpeng.com.au/wp-content/uploads/JetGuard_Family_B_With_Brand_20kw_10kw_20210218_5690-Web.png)
Benefits of JetGuard® for Underground Mining Operations
Models
![JetGuard_Family_B_With_Brand_20kw_10kw_20210218_5690-Web Two JetGuard underground mine dewatering pumps](https://www.pumpeng.com.au/wp-content/uploads/JetGuard_Family_B_With_Brand_20kw_10kw_20210218_5690-Web.png)
Power Curves (50Hz & 60Hz)
![JetGuard Power Curve JetGuard Power Curve](https://www.pumpeng.com.au/wp-content/uploads/JetGuard-Power-Curve.png)
Specifications
Model | kW (Hp) | Discharge | Voltage (Hz) | Solids Passage in mm | Max Head in m (ft) | Max Flow l/s | Max Diameter mm | Height mm | Weight kg |
---|---|---|---|---|---|---|---|---|---|
JP1041291 | 10 (14) | 80 mm | 415 (50) | 5 | 53 (173) | 23 | 358 | 780 | 140 |
JP1041391 | 10 (14) | 80 mm | 1000 (50) | 5 | 53 (173) | 23 | 358 | 780 | 140 |
JP1041491 | 10 (14) | 80 mm | 600 (60) | 5 | 53 (173) | 23 | 358 | 780 | 140 |
JP1041591 | 10 (14) | 80 mm | 480 (60) | 5 | 53 (173) | 23 | 358 | 780 | 140 |
JP1041791 | 10 (14) | 80mm | 1000 (60) | 5 | 53 (173) | 23 | 358 | 780 | 140 |
JP2031291 | 20 (27) | 100 mm | 415 (50) | 5 | 60 (196) | 37 | 475 | 787 | 180 |
JP2031391 | 20 (27) | 100 mm | 1000 (50) | 5 | 60 (196) | 37 | 475 | 787 | 180 |
JP2031491 | 20 (27) | 100 mm | 600 (50) | 5 | 60 (196) | 37 | 475 | 787 | 180 |
JP2031591 | 20 (27) | 100 mm | 480 (60) | 5 | 60 (196) | 37 | 475 | 787 | 180 |
JP2031791 | 20 (27) | 100 mm | 1000 (60) | 5 | 60 (196) | 37 | 475 | 787 | 180 |
Motor Specifications | |
---|---|
Pole | 2-Pole |
Insulation Class | Class F/H |
Motor Power Details | 1000 V, 415 V 50 Hz 480 V, 600 V & 1000 V 60 Hz |
Max Liquid Temp | Fluid at 40º C |
Max Submergence | 22 m |
Pump Specifications | |
---|---|
Impeller | 27 Chrome |
Wear Parts | 27 Chrome / CD4 |
Mechanical Seal | TC/TC/SS |
Bearing | Heavy duty bearings |
Outer Jacket | Stainless Steel |
Shaft | Stainless Steel |
